RedStuff Intumescent Water & Gas Tight Duct Sealant

Fire-Tested Performance
Independently tested to BS EN 1366-4:2021 (Linear Joints), providing proven fire protection when used in duct and penetration sealing applications.

FyBrid Technology
Developed with our proprietary FyBrid formulation, RedStuff offers enhanced durability, flexibility, and long-term performance under demanding conditions.

Non-Hazardous & Installer Safe
A neutral-curing, MEKO-free, halogen-free compound that is safe for use in confined spaces and explosive atmospheres (Ex zones), with no harmful emissions.

Visual Safety Identification
Formulated with a red pigment (<1%) for easy visual identification in fire-rated installations. The pigment is the only difference from GreyStuff, with no impact on fire resistance, curing, or handling.

Intumescent Properties
Expands when exposed to heat, sealing gaps around cables and ducts to prevent the spread of fire, smoke, and gases.

Single-Component Application
Ready-to-use straight from the cartridge. No mixing required, reducing installation time and ensuring consistent results.

Minimal Cable De-Rating
At a 20mm thickness, RedStuff achieves a thermal resistance of 5.1 K/W, allowing cables to maintain their full current-carrying capacity without overheating.

Water, Gas & Smoke Barrier
Provides long-lasting sealing protection against groundwater, harmful gases, hydrocarbons, and smoke ingress.

Microbial Defence
Enhanced resistance to fungi and bacteria, ensuring reliability in damp or contaminated environments.

Proudly British Made
Designed and manufactured in the UK, ensuring consistent quality, compliance, and secure supply.

Cure Time
RedStuff cures at approximately 3–4mm per day, depending on ambient humidity and temperature. Higher humidity and warmer conditions accelerate curing.

A minimum application thickness of 20mm is required to achieve effective fire, water, and gas sealing performance.

Cleaning
Uncured RedStuff can be easily cleaned with a solvent-based wipe. Once cured, it must be removed mechanically.

Health & Safety
RedStuff is a neutral-curing, MEKO-free, halogen-free formulation, making it non-hazardous and safe for installers in confined spaces and explosive atmospheres (Ex zones).

Re-Entry & Removal
Once cured, RedStuff achieves a rubber-like hardness similar to a pencil eraser. This makes re-entry and removal possible when required.

Use sharp tools for easier removal.

Only re-enter ducts when cables are de-energised.

AC Cable Solutions accepts no responsibility for damage caused during re-entry works.

Cable Suitability
RedStuff is a single-component, solvent-free system. It will not damage cable sheaths or stain duct/concrete surfaces.

Fire Testing & Certification
RedStuff has been independently tested to BS EN 1366-4:2021 (Linear Gap Seals). It is identical in formulation to GreyStuff, with the only difference being the red pigment (<1%), which has no impact on fire resistance, curing behaviour, or physical properties. The red pigment provides clear visual identification in fire-rated applications.

Storage & Shelf Life
Store RedStuff in a cool, dry place away from direct sunlight.

Shelf Life: 12 months unopened
Once opened: reseal securely and use within 1 month.

NOTE: Fire Test was performed on RedStuff, Not GreyStuff.  Please read further before purchasing

Tested by UL Germany to BS EN 1366-4:2021 (Linear Joints)

Solid Wall (150 mm thickness)
Joint length: 1m
Joint width: 25mm
Sealant depth: 20mm (RedStuff)
Backing: 25mm Rockwool Type Y RWA45 (45kg/m³ mineral wool)
Fire resistance: 240 mins integrity & insulation

Flexible Wall (asymmetrical construction)
One face: 2 × 12.5mm plasterboard
Opposite face: solid wall
Joint length: 3m
Joint width: 25mm
Sealant depth: 20 mm (RedStuff)
Backing: 25 mm Rockwool Type Y RWA45 (45 kg/m³ mineral wool)
Fire resistance: 90 mins integrity & insulation

Note: Fire Certification – Important Note

Fire resistance is only applicable to an “as fire tested” system or otherwise approved configuration. The system achieves the certified rating only when the exact tested proprietary product is installed in the same way as approved during testing.

Always ensure your installation matches our fire test certification.

End users are responsible for verifying that GreyStuff is the correct system for their project.

For copies of fire test reports, please contact our technical department.

What is RedStuff?
RedStuff is a single-component, MEKO-free, neutral-curing intumescent sealant developed with FyBrid technology. It provides flexible, durable sealing performance for cable ducts, pipe penetrations, and linear gaps, with the added benefit of red pigmentation for visual identification in fire-rated installations.

Is RedStuff fire tested?
Yes. RedStuff has been independently tested to BS EN 1366-4:2021 (Linear Joint Seals), confirming its suitability as a fire-resistant duct sealing compound.

What is the difference between RedStuff and GreyStuff?
The formulations are identical, with the only difference being the red pigment (<1%). This pigment does not affect fire performance, curing speed, chemical resistance, or handling properties. The red colour simply provides clear visual identification in fire safety applications.

Why is RedStuff red?
The red pigment is intended to provide immediate visual recognition in fire-rated installations, allowing inspectors, specifiers, and contractors to quickly identify safety-critical seals.

Is RedStuff safe to use?
Yes. RedStuff is MEKO-free, solvent-free, and halogen-free, making it non-hazardous and safe to use in confined spaces and explosive atmospheres (Ex zones).

Can RedStuff be re-entered or removed?
Yes. Once cured, RedStuff reaches a rubber-like hardness, allowing ducts to be re-entered or resealed if required.
Removal is easier with sharp tools.
Only attempt re-entry when cables are de-energised.

Does RedStuff damage cables?
No. RedStuff is solvent-free and has been tested for compatibility with a wide range of cable sheaths. It does not damage insulation or stain concrete/duct surfaces.

How long does RedStuff take to cure
Cure rate is typically 3–4mm per day, depending on humidity and temperature.

Can RedStuff reduce cable performance?
No. At a 20mm thickness, RedStuff has a thermal resistance of just 5.1 K/W, ensuring minimal cable de-rating and allowing cables to operate at full current capacity.

Where can RedStuff be used?
RedStuff is suitable for:

• Cable ducts and pipe penetrations (Only Fire Resistant when used with DuctSeal FR)
• Linear gap seals (tested to BS EN 1366-4:2021)
• Trefoil/triplex cable arrangements (when used within DuctSeal systems)
• Critical installations in water utilities, data centres, petrol forecourts, power distribution, and civil infrastructure

Where is RedStuff manufactured
RedStuff is proudly manufactured in the UK, ensuring consistent quality, supply reliability, and compliance with British and European standards.
